Excellent Dispense Volume Reliability
Model TP-40BA
- DC Servo motor pump for constant dispenses
- Automatic Charging system for buffer tank
- Automatic Degassing Function
- Step dispenses
- Outer Type Bellows
- Ball Screw equipped with Servo Motor
- Controller is integrated in pump assembly
- 7 Recipes can be applied
- Touch pad can control up to 16pumps
Configuration
Specifications
| Process | Description |
| Maximum Dispense Volume | 0.5cc~7.0cc |
| Dispense/Reload Rate | 0.1cc/sec~7.0cc/sec |
| Dispense Volume Resolution | 0.0025cc |
| Dispense Repeatability | ≤±0.02(2.2cp, 23℃) |
| Viscosity | Max : 150cp |
| Utility | Description |
| Electric power | 24VDC/1A |
| Main Air | 0.1~0.3Mpa |
| Resist In/Out | 1/4 Inch Teflon |
| Hardware | Description | |
| Weight | Touch pad | 0.64kg |
| Pump | 4.84kg | |
|
Dimension |
Touch pad | 140x44x88 |
| Pump | 80x210x309 | |
Characteristics
