Overview
CTW 100 is designed to comply with GMDSS requirement in accordance with SOLAS convention, IMO, ITU, IEC performance standards for survival craft Two-way VHF radio telephone apparatus used for both emergency and on-board communication.
CTW100 is fully capable of providing ITU, USA, Russian, Canadian and User defined channels including CH.16 established for 150MHz-band maritime mobile service.
Features
- The smallest, the most lightweight
- Safe and rovust construction
- High capacity battey operating more than 8 hours
- Multiple selection function
- Easy-to-use structure for unskilled person
- Watertight to a depth of 1 m for at least 5 min
- Clearly visible of yellow color
- External Mic/Speaker available (optional)
Specification
| General |
| Frequency range | 156.300 - 156.875MHz |
| Regular Output Power | HIGH-3.0W/LOW-0.5W |
| Radio Wave Type | 16KOF3E |
| Communication Methods | Simplex |
| Usable Channels | 19 Channels |
| Channel Space | 25kHz |
| Warming Up Time | Within 5 Sec |
| Supplied Voltage | 400mm (Height with Antenna), 136mm (Diameter) |
| Operating Time | Over 8 Hour (TX 10%, RX 10%, standby 80%) |
| Operating Temperature | -20°O + 55°C |
| Water Resistance | contains not less than 5 min at 1m depth |
| Dimension | 51(W)x (33D)x 104(H)mm |
| Weight | Primary Battery Installed - 250g (Main-body: 163g, Battery: 87g) |
| Secondary Battery Installed - 280g (Main-body : 163g, Battery : 117g) |
