Description
도면
사양
| No. ＼ Code | 내경 | 전장 | 외경 | ℓ | C | Sinter Swing |
중량 (g) Weight |
| dØ | L | DØ | |||||
| LD-6 | 6 +0.012-0 | 86 +0.6-0.8 | 16 ±0.10 | 17.5 | 30 | 0.10 | 100 |
| LD-8 | 8 +0.015-0 | 86 +0.6-0.8 | 16 ±0.10 | 17.5 | 30 | 0.10 | 90 |
| LD-10 | 10 +0.015-0 | 102 +0.6-0.8 | 20 ±0.10 | 21.5 | 34 | 0.14 | 160 |
| LD-12 | 12 +0.018-0 | 125 +0.6-0.8 | 24 ±0.10 | 27.0 | 41 | 0.14 | 300 |
| LD-14 | 14 +0.018-0 | 143 +0.6-0.8 | 28 ±0.10 | 28.5 | 49 | 0.14 | 500 |
| LD-16 | 16 +0.018-0 | 158 +0.6-0.8 | 32 ±0.15 | 31.5 | 54 | 0.14 | 650 |
| LD-18 | 18 +0.018-0 | 180 +0.6-0.8 | 36 ±0.15 | 37.5 | 60 | 0.20 | 950 |
| LD-20 | 20 +0.021-0 | 188 +0.6-0.8 | 40 ±0.15 | 37.5 | 64 | 0.20 | 1,200 |
| LD-22 | 22 +0.021-0 | 200 +0.6-0.8 | 44 ±0.20 | 38.0 | 70 | 0.20 | 1,550 |
| LD-25 | 25 +0.021-0 | 220 +0.6-0.8 | 50 ±0.20 | 39.5 | 80 | 0.20 | 2,200 |
| LD-30 | 30 +0.021-0 | 275 +0.7-0.9 | 60 ±0.20 | 52.5 | 97 | 0.25 | 4,000 |
| LD-35 | 35 +0.025-0 | 310 +0.7-0.9 | 70 ±0.20 | 57.5 | 110 | 0.25 | 6,050 |
| LD-40 | 40 +0.025-0 | 350 +0.7-0.9 | 80 ±0.25 | 66.5 | 122 | 0.25 | 9,500 |
| LD-45 | 45 +0.025-0 | 390 +0.7-0.9 | 90 ±0.25 | 74.0 | 140 | 0.25 | 12,000 |
| LD-50 | 50 +0.025-0 | 426 +0.7-0.9 | 100 ±0.25 | 77.0 | 156 | 0.25 | 17,600 |
| LD-60 | 60 +0.030-0 | 485 +0.7-0.9 | 120 ±0.25 | 80.0 | 185 | 0.25 | 30,000 |
