Description
Drawing
Specification
| Model No. | Material | Max.Speed (rpm) |
Max.Torque (kgf.m) |
A (mm) |
B (mm) |
C (mm) |
D (mm) |
E (mm) |
F (mm) |
| HH-315-CK-03L | SNCM815 | 1,800 | 20,000 | 310 | 134 | 110 | Ø110 | 12 | 12 |
| HH-315-CK-03M | SNCM420 | 1,700 | 18,000 | ||||||
| HH-315-CK-03C | SNCM220 | 1,500 | 15,500 | ||||||
| HH-345-CK-03L | SNCM815 | 1,800 | 30,000 | 341 | 148 | 116 | Ø123 | 16 | 16 |
| HH-345-CK-03M | SNCM420 | 1,700 | 27,000 | ||||||
| HH-345-CK-03C | SNCM220 | 1,500 | 23,000 | ||||||
| HH-380-CK-03L | SNCM815 | 1,800 | 35,000 | 373 | 162 | 130 | Ø136 | 16 | 16 |
| HH-380-CK-03M | SNCM420 | 1,700 | 31,500 | ||||||
| HH-380-CK-03C | SNCM220 | 1,500 | 26,800 | ||||||
| HH-400-CK-01L | SNCM815 | 1,500 | 26,000 | 200 | 180 | 150 | Ø400 | 30 | 80 |
| HH-400-CK-01M | SNCM420 | 1,350 | 23,500 | ||||||
| HH-400-CK-01C | SNCM220 | 1,200 | 19,900 | ||||||
| HH-400-CK-02L | SNCM815 | 1,800 | 25,000 | 390 | 168 | 140 | Ø136 | 14 | 14 |
| HH-400-CK-02M | SNCM420 | 1,700 | 22,500 | ||||||
| HH-400-CK-02C | SNCM220 | 1,500 | 19,000 | ||||||
| HH-450-CK-01L | SNCM815 | 1,500 | 38,000 | 290 | 265 | 173 | Ø450 | 36 | 92 |
| HH-450-CK-01M | SNCM420 | 1,350 | 34,200 | ||||||
| HH-450-CK-01C | SNCM220 | 1,200 | 29,000 | ||||||
| HH-600-CK-04L | SNCM815 | 1,800 | 140,000 | 592 | 237 | 201 | Ø202 | 18 | 18 |
| HH-600-CK-04M | SNCM420 | 1,700 | 126,000 | ||||||
| HH-600-CK-04C | SNCM220 | 1,500 | 107,000 |
