SPECIFICATIONS

EQUIP. DIMENSION

1,830W x 3,070L X1,550H / mm

WEIGHT

2000Kg

CUTTING SIZE

1200 x 1200mm (Max size)

CUTTING THICKNESS

0.1~1mm

CUTTING SPEED

16~50cuts/min

CUTTING ACCURACY

±0.1mm

MODEL MEMORY

90 model

BLADE SPEC

1214x18.5x0.25t

UTILITY

MAIN POWER:3Ø, 220V±10%, 2.5KW, 50/60Hz

Air  : 5~6Kg/㎠, Ø8Hole, 20L/min
