SPECIFICATIONS

EQUIP. DIMENSION

920(L)mm×650(W)mm×1770(H)mm

WEIGHT

220Kg

PANEL SIZE

16~75(W), 15~61(L) <3.5”max>

PANEL THICKNESS

(0.3~1.1)*2mm

1 FPC BONDING TIME (S/T)

20sec (bonding time 15sec 시)

FPC THICKNESS

0.1~0.2mm

PATTERN PITCH

0.1mm(max)

BONDING ACCURACY

±12~15 ㎛

EMPERATURE

Room Temperature ~ 350℃(controller 상)

UTILITY

MAIN POWER:220V±10%,1.2KW, 50/60Hz

AIR : 5~6 Kg/cm2, 240L/min, Ø10 Hose
