SPECIFICATIONS

MODEL	VPDB
Operating Fluid	Mineral Oil (ISO VG15~32)
Temperature Range	-20℃ ~ 80℃
Operating Pressure (max.)	135 bar
Power Supply	110/220V AC, 50/60 Hz
Output Signal	Dry Contact (Open/Close)
	Indicating Lamp (Power/Open/Close)
	Fault Alarm
Applicable Power Pack	VRCS HPU

FEATURES
SOLAS Chap. Ⅱ-1 / Part B-2-Reg. 12.5.1
Available in double acting type multi turn actuator.
All VRCS makers available.
Fault alarm indicating in the abnormal work.
The exact valve position indicate.
