SPECIFICATIONS

MODEL		DEGR-ST		DEGR-AG
Item		Standard TIER III Valve		Acid resistant III Valve
Application Position		RTV/RBV/EGB/CBV	TCO	BCO	CCO/BPCO/ESD
Working Fluids		Exhaust gas
Temperature Range		200℃ ~ 500℃(Max. 550℃)		25℃ ~ 75℃(Max. 200℃)	25℃ ~ 75℃(Max. 200℃) or 25℃ ~ 500℃(Max. 550℃)
Actuator Type		Rack & Pinion, Pneumatic
Valve Size		400A ~ 2000A		200A ~ 500A	200A ~ 800A
End Connection		JIS / DIN / ISO / ANSI Standard
Material	Body	Cast Steel, Ductile Cast Iron, Stainless Steel
	Trim	Cast Steel, Ductile Cast Iron, Stainless Steel

FEATURES
It ensure proper operation of engine and EGR system (Gas-liquid fluid composition) by using 4-7 difference butterfly valves.
Various type according to application position.
There are Standard type and Acid resistant type.
