SPECIFICATIONS

MODEL		SV-OL, CL, CC	SV-LF	SV-HF
Working Fluids		Steam, Air, Water, Liquid
Temperature Range/Press		-20℃ ~ 220℃ / 30K
Valve Type		Full Bore	Low Lift	High Lift
Valve Size		15A ~ 200A	15A ~ 50A
End Connection		JIS / DIN / ISO / ANSI Standard
Material	Body	Cast Steel, Ductile Cast Iron, Cast Bronze
	Trim	Stainless Steel

FEATURES
Simple design and excellent seat tightness.
Rapid opening action at over-set pressure.
Various caps or lever as airtight or emergency operating.
Compact structure for maintenance.
