SPECIFICATIONS

MODEL		RG-CY	RD-DP	RD-PL	RD-CH
Working Fluids		Air, Gas, Liquid,Vater		Steam	Air
Temperature Range/Press		-20℃ ~ 150℃ / 20K		220℃ / 20K	-20℃ ~ 150℃ / 30K
Valve Type		Cylinder	Diaphragm	Pilot	Handle
Valve Size		15A ~ 50A	15A ~ 80A	15A ~ 150A	15A ~ 50A
End Connection		JIS / DIN / ISO / ANSI Standard
Material	Body	Cast Steel, Ductile Cast Iron, Cast Bronze
	Trim	Stainless Steel
Accessory		Glycerin Port

FEATURES
Proportion control type valve for secondary pressure regulating.
Being self-control type, so an auxiliary power is not required.
Disassembling inner parts without disconnecting a pipe.
Compact structure for maintenance.
Large capacity as pilot type design.
