SPECIFICATIONS

MODEL		MHPP	MHPB	MHPU
Operating Fluid		Mineral Oil (ISO VG15~32)
Temperature Range		-20℃ ~ 80℃
Actuator Type		Deck Stand	BOX	Electronic Motor
Operating Pressure (max.)		135 bar
Working Pressure	Open	110 bar
	Close	100 bar
Applicable Valve Type		Multi Turn Hydraulic Motor
Accessory (option)		Relief Valve, Emergency Handpump Self-seal coupling
Position Indicating device		Flow indicating, Limit Switch indicating

FEATURES
SOLAS Chap. Ⅱ-1 / Part B-2-Reg. 12.5.1
Available in double acting type multi turn actuator.
Making available a variety of forms.
The exact valve position indicate.
In conjunction with VRCS available.
