SPECIFICATIONS

MODEL		RG-CY	RG-DP
Working Fluids		Air, Water, Liquid, Oil
Temperature Range/Press		-20℃ ~ 150℃ / 20K
Valve Type		Cylinder	Diaphragm
Valve Size		15A ~ 100A	15A ~ 100A
End Connection		JIS / DIN / ISO / ANSI Standard
Material	Body	Cast Steel, Ductile Cast Iron, Cast Bronze
	Trim	Stainless Steel
Accessory		Glycerin Port

FEATURES
Proportion control type valve for secondary pressure regulating.
Being self-control type, so an auxiliary power is not required.
Disassembling inner parts without disconnecting a pipe.
Compact structure for maintenance.
