SPECIFICATIONS

MODEL		TR-BL	TR-DT		TR-PL
Working Fluids		Steam, Hot Water, Thermal Oil
Temperature Range		-20℃ ~ 220℃
Valve Type		Bellows	Direct		Pilot
Valve Size		15A ~ 50A			32A ~ 125A
End Connection		JIS / DIN / ISO / ANSI Standard
Material	Body	Cast Steel, Ductile Cast Iron, Cast Bronze
	Trim	Stainless Steel
Accessory (option)		Heater Sensor (0~60, 50~110, 80~140)Globe, Angle
Capillary Tube Lenght (m)		5m (Option)3,7,8 ~15m50A-800A

FEATURES
Proportion control type valve for secondary pressure regulating.
Being self-control type, so an auxiliary power is not required.
The installation and maintenance is very easy.
Simple construction and steady operation.
