Pressure Input Signal

Standard : 0-10 VDC

Set Point

Programmable

External Analog

5 total, programmable in any combin for pressure or position

(adjustable from the front panel or RS232/RS485 selectable from the front panel, TTL, or RS232/RS485)

0-10 VDC

Controller Repeatability

±0.1% of F.S

Ambient Operating

Temperature

150C - 450C

Output Power

±15 VDC ±5% @ 1.5 Amp

Analog Output Signal

0-10 VDC for 0-100% valve position  and 0-10 VDC for 1-100%, F.S pressure

Size

1/2-rack packing : 88mm H x 241mm W x 225 D

Display

240x(RGB) X 320 pixels Transmissive LCD

 (pressure, position and external set-point readout)

Display Units

Soft Start

Torr, mTorr, mbar, Pascal, cmH20, inH20, mbar, kpa Standard

PID Control

Standard

Remote Zero

Standard

Interface

Front panel, Analog, TTL and RS232 , RS485

Relay Output

2, process limits : 24 Volts AC/DC 0.5Amp resistive

Remote Control Override

(Open, Close, Hold)

Standard

Position Control

Capability

Standard

Battery Backup

N/A
