Description
수치표
| 모델 | A | B | C | C1 | D | E | F | ØG | H | ØI | J | ØK | L | M |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FA-2016EA S/C | M20X1.5 | 16 | 105 | 122 | 89 | 63 | 10 | 6 | 17 | 18 | 16 | 26 | 10 | 24 |
| FA-2725FA S/C | M25X1.5 | 25 | 136 | 156 | 111 | 84.5 | 10 | 8 | 20 | 23 | 16.5 | 35 | 12 | 32 |
사양
| 형식 | FA-2016EA | FA-2725FA |
|---|---|---|
| 스토로그(mm) | 16 | 25 |
| 최대흡수에너지 J(kgf/m) | 25.4(2.6) | 79.3(8.1) |
| 최대등가질량(kg(kgf)) | 200(200) | 500(500) |
| 가변속도범위(m/s) | 0.15~3 | 0.15~3 |
| 최대항력치(N(kgf)) | 9800(1000) | 11760(1200) |
| 1분당 최대 흡수에너지 J(min) (kgf m/min) |
343(35) | 539(55) |
| 피스톤로드복귀력(N(kgf)) | 35.2(3.59) | 44.2(4.51) |
| 사용온도범위 (℃) | -5~70 | -5~70 |
| 질량(S Type) (g) | 190 | 400 |
| 질량(C Type) (g) | 260 | 600 |
