Product Details

Ion Sputter Coater-II (PVD for R&D)

Product Description : Ion Sputter Coater/Thermal-evaporation/Glow-discharge, Plasma treatment

Features

Three modes for easy selection!
1. Coating Function : Ion Sputter Coater
2. Evaporation Function : Thermal-evaporation
3. Arc Discharge : Glow-discharge, Plasma treatment
Various applications including Au, Pt, and carbon

Specifications

HIGHLIGHTS AND FEATURES

Light-weight design aluminum receptacle

Glass reaction cylinder Ø120mm (DIN 100 ISO-KF compatible)

Implosion guard and safety monitoring

Round stage, height-adjustable, and tiltable (Ø80mm) to hold your samples.
The table can be easily removed without tools for cleaning purposes.

Speed-controlled rotary or planetary gear table with different options for holding samples (option)

Coat-thickness measurement via double-quartz measuring system
(small samples at the center, large samples at the edge)

Wide range power supply (90-260VAC)

Interface for different process heads with automatic recognition

5.7“ TFT-Touch graphical display

Easy creation of coating formulations, which guarantee reproducible results

Storage/view of the last ten processes

Feature for automatic flooding of system in the event of power loss.
This prevents the system from becoming contaminated with backing pump oil.

Intuitive user software with many practical features

Graphical representation of process data with Windows-based Coating LAB software

Etc..

– Flange connection (DN 25 ISO-KF) for connecting an external backing pump (LV version)
– Can be used as a pure pumping unit
– External alarm output
– USB interface for easy analysis and update of software
– Automatic valve control for two process gases and venting
– 6mm Legris connections for two process gases and a venting gas
– Tools for target and quartz replacement
– USB service cable
– Power supply cable
– Various accessories and mounting materials included in scope of delivery
