PRINTING SPECIFICATION

• METHOD : Direct Thermal
• SPEED : 80mm/sec
• WIDTH : 104mm, 832 Dots/line
• RESOLUTION : 203 DPI

PAPER SPECIFICATION

• TYPE : Thermal receipt / Label
• WIDTH : 50~112mm
• THICKNESS : 0.06~0.16mm
• ROLL DIAMETER : Max. Ø 56mm
• ROLL CORE INNER DIAMETER : 12.5mm ± 0.5mm

INTERFACE

• STANDARD : Serial(RS-232C), USB
• OPTION : Bluetooth Class 2, Wi-Fi(802.11 b/g)

Key Feature

- Receipt/Label Printer

- High glossy cover and 3 color LEDs

- Adjustable paper width from 50.4mm to 112mm

- 2 types of battery selectable : 2200/4400mAh

- Large capacity paper rolls up to 56mm(OD)

- Highly reliable Bluetooth communications or Wi-Fi(802.11 b/g) available(Option)

- ESC/ POS, CPCL command compatible

- IP54(with case) certified
