PRINTING SPECIFICATION

• METHOD : Thermal Transfer and Direct Thermal
• SPEED : Max. 127 mm/sec
• WIDTH : 104 mm (4.1)
• PRINT LENGTH : 1,000 mm (39.3)
• RESOLUTION : 203 DPI (8 dots/mm)

PAPER SPECIFICATION

[ PAPER ]
• TYPE : Label roll, Fanfold
• WIDTH : 20~ 114 mm (0.7 ~ 4.48)
• THICKNESS : 0.065mm ~ 0.254 mm

[ RIBBON ]
• WIDTH : 110mm
• LENGTH : 75M

INTERFACE

• STANDARD : USB, Serial(RS-232C), Ethernet

Key Feature

- Compact desktop label printer

- Rapid graphic printing at 127mm/sec

- Paper width adjustable from 20mm to 114mm

- Labeling software ‘Label Cooker’ supplied as a professional solution

- EPL II, ZPL II Command compatible

- Standard interface capabilities : USB, Serial(RS-232C), Ethernet

- Easy to replace paper and ribbon

- The vertical directional interface that is designed for the convenience of replacing the external paper

- Compact size to maximize the space utilization (Lowest height in its class)
