PRINTING SPECIFICATION

• METHOD : Direct Thermal
• SPEED : 80mm/sec
• WIDTH : 48mm(384 Dots/Line)
• RESOLUTION : 203 DPI

PAPER SPECIFICATION

• TYPE : Thermal Receipt, Linerless(Optional)
• WIDTH : 58mm
• THICKNESS : 0.06-0.09 mm
• ROLL DIAMETER : Max. Ø 40mm
• ROLL CORE INNER DIAMETER : 12.5mm ± 0.5mm

INTERFACE

• STANDARD : Serial(RS-232C), USB
• OPTION : Bluetooth Class 2

Key Feature

- Receipt only

- Light weight(240g with battery) & with robust durable structure

- Compact size : 80mm x 132.5mm x 46.8mm(W x D x H)

- Drop resistance : 1.2M onto concrete

- Lithium- ion rechargeable battery : 130M(about 1300 pieces) printable

- Prints at 80mm per second

- Dual headed MSR(Optional)

- Equipped power options AC/DC charger and vehicle charger(12/24V)​
