SPECIFICATIONS
|
1. AUTO SHEET FEEDER
|
3. SHEET CUPPING PRESS
|
5.TRANSFER PRESS & LINER
|
|
Capacity
|
Max. 25Sheets/min
|
Press Capacity
|
30Tf
|
press Capacity
|
30Tf
|
|
Sheet thickness
|
Max. T=0.4
|
Stroke per Min
|
110spm
|
Stroke Per Min
|
110 spm
|
|
Max. Sheet Size
|
1060x1060 mm
|
Open Height
|
480mm
|
Die Height
|
360mm
|
|
Max.Loading Weight
|
2 TON
|
Slide Stroke Lenght
|
130mm
|
Open Height
|
480mm
|
|
Horse Power Required
|
3.75 KW
|
Die Height Adjust
|
±10mm
|
Slide Stroke Length
|
30mm
|
|
Vacuum Pump
|
1.5kw, 600L/MIN
|
Slide Area
|
900x200mm
|
Die Height Adjust
|
±10mm
|
|
Air Conusumpion
|
40L / MIN
|
Bed Area
|
900x200mm
|
Slide Area
|
900x200mm
|
|
Machinery Weight
|
1500 KG
|
Table Height from FL
|
830mm
|
Bed Area
|
900x200mm
|
|
Floor Space
|
1670 x 2000 mm
|
Main Motor
|
7.5kw x 6p, 1150rpm
|
Number of Stations
|
(3+1) x 6 set
|
|
Height Over All
|
1669 mm
|
Compressed Air
|
5kg / ㎠
|
Table Height form FL
|
1000mm
|
|
2. SHEET TRANSFER M/C
|
Air Consumption
|
350 L/MN
|
Main Motor
|
7.5kw x 6p, 1150rpm
|
|
MAX. Sheet Size
|
1060x1060 mm
|
Oil Tank Volume
|
50 Liter
|
Compressed Air
|
5kg/㎠
|
|
Serov
|
3kw(1ea)2kw(1ea)
0.7kw(1ea)
|
Floor Space
|
W 2600 x D 1140
|
Air Consumption
|
350 L/MN
|
|
Double Sheet Detactor
|
1 SET
|
Height Over All
|
2600mm
|
Oil Tank Volume
|
50 Liter
|
|
Air Consumption
|
120 L/MIN
|
Gross Weight
|
Approx. 800kg
|
Floop Space
|
W 2600 x D 1140
|
|
Hores Power Required
|
5.62 kw
|
Die Hight
|
360mm
|
Height Over All
|
Approx. 800kg
|
|
Floor Space
|
1700x3200 mm
|
4. ACCUMULATION CONVEYOR
|
Gross Weight
|
360mm
|
|
Height Over All
|
1170mm
|
Press Power Required
|
1.5 kw
|
8. CONVEYOR
|
|
6. CONVEYOR
|
Belt
|
Plastic Top Chain
|
Horse Power Required
|
0.75kw
|
|
Horse Power Required
|
0.75kw
|
7. DRYEY
|
Belt
|
plastic Top Chain
|
|
|
|
Min Converor Motor
|
2.2Kw
|
9. PACKING
|
|
|
|
Electronic Heart
|
76kw + 6kw
|
Horse Power Required
|
0.75kw x 2
|
|
|
|
Fan Motor
|
0.4kw x 6Set
|
Conveyor
|
2 Set
|
|
|
|
Cooling Fan Motor
|
0.4kw x 3set
|
Delivery Conveyor
|
Roller Type
|
|
|
|
Chain,Mesh Belt
|
sus 304
|
Divider
|
1 Set
|
|
|
|
Floor Space&Height
|
8000x1600x2000mm
|
Count
|
1Set
|
|
|
|
|
|
|
|
FEATURES
* COMPETITIVE PRICE AND GOOD QUALITY
* VARIOUS SIZES WITH EASY CHANGEABLE DIE SET MOLD.
* MULTI DIE SET MOLD
* ZIGZAG & STRAIGHT FEEDING SYSTEM.
* TOUCH SCREEN : EASILY CHECK MACHINE RUNNING CONDITION AND PROBLEMS.
* TRANSPARENT OIL DISTRIBUTOR SYSTEM : EASY TO CHECK OIL RUNNING AND SHORT OF OIL
* HIGH TECH SENSOR : MACHINE WILL STOP WHEN PRODUCT DOES NOT RUN SMOOTHLY.
* HIGH RIGID FRAME : RATIONALLY DESIGNED FRAME KEEPS SUFFICIENT STRENGTH AND MAINTAINS ACCURATE
PRECISION FOR DYNAMIC LOAD.
* ANGLE SEQUENCER CONTROL : PRECISE CONTROL INFORMATION IN RUNNING AND OPERATING WHICH IS
SIMPLE PROGRAMMABLE ENABLES TO STOP AT THE TOOP DEAD POINT AUTOMATICALLY IN ANY SPEED.
* INVERTOR IS AVAILABLE RUNNING SPEED.
* SAFETY : PUTTING THE TRANSPARENT WINDOW IN FRONT OF DIE SET MOLD, EASILY CHECK THE PROBLEM
AND WORKER CAN STAY AWAY FROM SAFETY ACCIDENT.
* PLC CONTROL.
