SPECIFICATIONS
|
AUTO TRANSFER PRESS
|
|
PRESS CAPACITY
|
40 FT
|
|
DIE HEIGHT
|
400 MM
|
|
DIE HEIGHT ADJUSTMENT
|
±20 MM
|
|
STROKE PER MIN.
|
MAX. 45 S.P.M
|
|
HORSE POWER REQUIRED
|
3.75 KW
|
|
OVER ALL HEIGHT
|
2480 MM
|
|
FLOOR SPACE
|
2700 X 1525 MM
|
|
NUMBER OF STATIONS
|
5 OR 6 STATIONS
|
|
NET WEIGHT
|
6500 KG
|
|
|
|
FEEDING MACHNIE
|
|
CAPACITY PER MIN
|
MAX. 45 C.P.M
|
|
HORSE POWER REQUIRED
|
06. KW
|
|
FLOOR SPACE
|
1890 X 400 MM
|
|
HEIGHT OVER ALL
|
1670 MM
|
|
NET WEIGHT
|
200 KG (APPROX.)
|
FEATURES
* COMPETITIVE PRICE AND GOOD QUALITY
* VARIOUS SIZES : EAST TO CHANGE SPOUT SIZE BY DIE SET MOLD
* SPECIAL FACE CAM : MINIMIZE SHAKING OF CARRIER FINGER.
* SAFETY : PUTTING SAFETY SENSOR IN FRONT OF DIE SET MOLD,
WORKER CAN STAY AWAY FROM SAFETY ACCIDENT AND EASY TO CHECK PROBLEMS ON MOLD.
* CENTRAL LUBRICANT OIL SYSTEM : OIL PUMP MAKES MACHINE SMOOTH AND LAST MACHINE LIFE.
* HIGH RIGID FRAME : RATIONALLY DESIGNED FRAME KEEPS SUFFICIENT.
* STRENGTH AND MAINTAINS ACCURATE PRECISION FOR DYNAMIC LOAD.
* INVERTOR IS AVAILABLE FOR VARIABLE RUNNING SPEED
* PLC CONTROL
