제품 상세 정보
PERFORMANCE GRAPH
GENERAL SPECIFICATION
| General Specification | ||
|---|---|---|
| Engine model | G6HD300 | |
| Type | 4 CYCLE TURBOCHARGED WITH INTERCOOLER | |
| RATED OUTPUT (WITHOUT FAN) | 325 PS / 2100 RPM | |
| MAX TORQUE | 128 kg.m / 1400 RPM | |
| NO. OF CYL & ARRANGEMENT | 6-IN LINE | |
| COMBUSTION CHAMBER TYPE | DIRECT INJECTION | |
| BORE X STROKE | 130 mm x 140 mm | |
| TOTAL PITON DISPLACEMENT | 11,149 cc | |
| COMPRETION RATIO | 16.5:1 | |
| ROTATION | COUNTER-CLOCKWISE ROTATION AS VIEWED FROM FLYWHEEL SIDE | |
| FIRING ORDER | 1-5-3-6-2-4 | |
| WEIGHT DRY | 1320 Kg(Approx) | |
| DIMENSION | LENGTH | 1811 mm |
| WIDTH | 1310 mm | |
| HEIGHT | 849 mm | |
| Gearbox | DMT140H | 1.97~3.46 |
※Weight : Transmission is included
