제품 상세 정보
PERFORMANCE GRAPH
GENERAL SPECIFICATION
| General Specification | ||
|---|---|---|
| Engine model | G4HD80 | |
| Type | 4 CYCLE TURBOCHARGED | |
| RATED OUTPUT (WITHOUT FAN) | 80 PS / 2400 RPM | |
| MAX TORQUE | 25.5 kg.m / 1800 RPM | |
| NO. OF CYL & ARRANGEMENT | 4-IN LINE | |
| COMBUSTION CHAMBER TYPE | DIRECT INJECTION | |
| BORE X STROKE | 100 mm X 105 mm | |
| TOTAL PITON DISPLACEMENT | 3,298 cc | |
| COMPRETION RATIO | 16.0:1 | |
| ROTATION | COUNTER-CLOCKWISE ROTATION AS VIEWED FROM FLYWHEEL SIDE | |
| FIRING ORDER | 1-3-4-2 | |
| WEIGHT DRY | 412 Kg(Approx) | |
| DIMENSION | LENGTH | 1292 mm |
| WIDTH | 656 mm | |
| HEIGHT | 780 mm | |
| Gearbox | DMT25AL | 1.64~3.32 |
※Weight : Transmission is included
