- Displacement : 669.6 cc/rev.

- Pressure : Max. 15 Bar

- Viscosity : Max. 200,000 cp

- Temperature : Max. 120 ℃

Dimensions

A : 190 mm , B : 42mm , C : 140mm , D : 140mm , E : 68mm , F : 42mm , G : 160mm , H : 132mm , I : 12x8 , J : 50mm , K :160mm , L (Standard): 477mm , L (Multi): 606mm , M : 81mm , N : 129mm , Inlet & Out let Dia. : 80A Flange , Diameter of Hole for Base : 13mm

Applications : Oil , Lubricant , Chemical , Clean liquid , etc..
