- Displacement : 2290 cc/rev.

- Pressure : Max. 7 Bar

- Viscosity : Max. 5,000 cp

- Temperature : Max. 120 ℃

Dimensions

A: 240 mm, B: 65mm, C: 185mm, D: 185mm, E: 88mm, F: 48mm, G: mm, H: 200mm, I: 14x9, J: mm, K: 210mm, L: 589mm, M: 100mm, N: 151mm, Inlet & Outlet Dia.: 125A Flange, Diameter for 4 Holes of Base: 17mm

Applications : Waste-Water, Chemical, Excretions, Sea-Water, Food, etc..
