- Displacement : 49.1 cc/rev.

- Pressure : Max. 5 Bar

- Viscosity : Max. 200,000 cp

- Temperature : Max. 120 ℃

Dimensions

A : 100 mm , B : 30mm , C : 70mm , D : 70mm , E : 37mm , F : 22mm , G : 75mm , H : 102mm , I : 7x7 , J : 42mm , K : 78mm, L (Standard): 264mm , L (Multi): 365mm , M : 37mm , N : 101mm , Inlet & Out let Dia. :25A PT , Diameter of Hole for Base : 13mm

Applications : Oil , Lubricant , Chemical , Clean liquid , etc..
