product Image
MITSUBISHI Marine Engine
모델명
MS12R-T2MPTK
시리즈
Marine Diesel Engine MITSUBISHI
자료
-
구매정보
provider logo
창흥산업(주)

선박엔진, 선박용 발전기, 산업용 기어

연락처
031-334-9622
이메일
changhung@changhung.co.kr
상품정보에 문제가 있나요?
정보수정 / 삭제요청
코머신은 제품 판매자가 아닙니다.법적고지 및 안내
제조사
창흥산업(주)[바로가기]
제품 타입
기계
브랜드
-
SKU
123741
제품명
MITSUBISHI Marine Engine
모델명
MS12R-T2MPTK
사이즈
-
중량
-
제품 상세 정보

MITSUBISHI Marine Engine, MS12R-T2MPTK (1415 / 1650)



Features


ModelMS12R-T2MPTK
Continous Rating Output (ps/rpm)1415 / 1650
Type4-cycle, water cooled, direct injection, diesel engine
AspirationTurbocharged with intercoolerNumber of CylinderV-12
bore (mm)170Stroke (mm)180
Total Piston Displacement (ℓ)49Compression Ratio14.5:1
Fuel OilDieselFuel Consumption (g/ps.h)155
Lubricating systemForced lubrication by gear pump
Lubricating oilAPI service grade CD class or higher
Cooling systemThermostat controlled fresh water cooling by fresh water pump,
heat exchanger and sea water pump
Fresh water pump typeCentrifugal type
Sea water pump typeRubber impeller type
Starting systemElectric starting motor
Fuel Injection PumpMITSUBISHI PS6 type with fuel feed pump
Dry Weight (kg)7000
