| Model | MS12R-T2MPTK |
|---|
| Continous Rating Output (ps/rpm) | 1415 / 1650 |
|---|
| Type | 4-cycle, water cooled, direct injection, diesel engine |
|---|
| Aspiration | Turbocharged with intercooler | Number of Cylinder | V-12 |
|---|
| bore (mm) | 170 | Stroke (mm) | 180 |
|---|
| Total Piston Displacement (ℓ) | 49 | Compression Ratio | 14.5:1 |
|---|
| Fuel Oil | Diesel | Fuel Consumption (g/ps.h) | 155 |
|---|
| Lubricating system | Forced lubrication by gear pump |
|---|
| Lubricating oil | API service grade CD class or higher |
|---|
| Cooling system | Thermostat controlled fresh water cooling by fresh water pump, heat exchanger and sea water pump |
|---|
| Fresh water pump type | Centrifugal type |
|---|
| Sea water pump type | Rubber impeller type |
|---|
| Starting system | Electric starting motor |
|---|
| Fuel Injection Pump | MITSUBISHI PS6 type with fuel feed pump |
|---|
| Dry Weight (kg) | 7000 |
|---|
