Automatic valve manufacturer, For Power plant, Energy, Petro chemical, Oil refining, Food, Paper, Shipbuilding, Pharmaceutical field
Application
■ Water distribution pipes
■ Industrial cleaning machines
■ Dyeing machine temperature control
■ Middle and low stem equipments control
■ Well water and wastewater disposal plant
Specification
| Valve Size | 15A ~ 50A |
| Actuator Type | Cylinder type |
| Actuator Action | Single acting (air to open, spring close) |
| Operating Media | Compressed dry air |
| Operating Press | 4 ~ 7kg/㎠ |
| Liner Adjust | None manual handle |
| Fluid Temp | -30 ~ 160℃ |
| Connection | Screw, Welding |
| Body Material | SUS304 |
| Leakage allowance | ANSI Class V (0.005%) |
| Accessory | Solenoid Valve, Air filter Regulator |
※ (Option)
