■ Features

- SPWM，Speed/Current alike close loop technology, smooth rotation

- Smooth torque output within speed range (8000 rpm Max.)

- 1：75 Max. speed regulation ratio

- 60°/300°/120°/240°Electrical angle adjustable

- Speed regulation： potentiometer adjust / Analog input

- Run/Step、Quick Brake、CW/CCW rotation shift

- Speed output、Alarm output（O.C.）

- Over current、over voltage、stall、missing speed Alarm





■ Parameters

Electrical Parameters（Tj＝25ºC)

Power	24～50VDC, Capacity：up to motors
Current output	Rated 15A，Peak 45A（≤3s
Driving mode	SPWM
Insulation Res.	＞500MΩ
Dielectric Strength	500V/Minute
Weight	About 300g



Ambient requirement

Cooling	Self cool
Environment	Keep away from oil, dust, and acid gas
Temperature	0ºC～＋50ºC
Humidity	＜80％RH
Vibration	5.7m/s2。Max.
Storage temp.	－20ºC～＋125ºC
