Video

Compression

H.264, MJPEG

Bitrate

Primary : 32Kbps ~ 16Mbps, Secondary : 32Kbps ~ 4Mbps

Resolution

320x240 ~ 1920x1080

Streaming

Primary : H.264, Secondary x 3 : H.264/MJPEG

Burn-in OSD

Multi-lingual

Input

1 x HDMI (Type A)

1 x Composite (BNC)

1 x 3G-SDI (BNC)

Output

1 x HDMI (Type A), Input Bypass

1 x Composite (BNC), Input Bypass

1 x 3G-SDI (BNC), Input Bypass

Audio

Compression

G.711 / AAC

Sampling rate

G.711 : 8 KHz, AAC : 32 kHz / 44.1 kHz / 48 kHz

Bitrate

G.711 : 64Kbps, AAC: 64Kbps/128Kbps

Streaming

G.711 : Full-duplex, AAC : Full-duplex

Input

1 x Line-In (stereo, mini-stereo type)

Output

1 x Line-Out (stereo, mini-stereo type)

Network

Interface

Ethernet 10/100/1000base-T (RJ-45)

Protocol

IPv4/v6, TCP, UDP, IGMP(Multicast), ICMP, DHCP, HTTP, HTTPS, RTP,

RTSP, RTMP, FTP, SNMP, SMTP, UPnP, WS-Discovery, Zero,

Configuration, NTP, DDNS, ONVIF, PSIA, MPEG-TS, SRT (Secure Reliable Transport)

Security

Password protection, IP address filtering, HTTPS encryption

API

Truen protocol/SDK

Event / Alarm

Event sources

Motion, Sensor input, Video loss, Client disconnection

Event actions

Notification(E-mail), FTP, PTZ preset, Alarm control, Recording

General

Housing

Aluminum

Certifications

CE, FCC, KCC, RoHS

External devices

2 x Sensor-In (dry contact, NO/NC)

2 x Alarm-Out (dry contact, NO)

1 x RS-232 port

1 x RS-422/485 port

1 x Buzzer (88dB min)

Power Supply

Min DC12V/1.0A, PoE(Power over Ethernet): 802.3af

Power Consumption

DC12V/PoE : Max 9.6W

Operating Temperature

-10°C ~ 50°C ( 14°F ~ 122°F )

Storage Temperature

-10°C ~ 50°C ( 14°F ~ 122°F )

Operating Humidity

20% ~ 80% RH

Storage Humidity

20% ~ 80% RH

Edge Storage

1 x USB 2.0 port

Dimensions (W x H x D)

134.08(W) X 125(D) X 33(H)mm

Weight

470g
