TTP-2610MT

ZT420 Compatible

Resolution : 203dpi(8dots/mm)
Printing Speed : 102mm-305mm per second(4.0-12.0ips)
Memory :  512MB Flash, 256 MB DRAM
              SD 4G flash memory card slot for flash memory expansion
Width : 168 mm (6.61")
Length : 14,732 mm (580“)

Material : Metal Body
Operation Panel : LED(Power, Error, On line), Switch
Dimension : 355 mm (W) x 337 mm (H) x 520 mm (D)

Weight : 23kg
Sensors : Label gap, Ribbon end, Black-mark, Head open, Case open, Peel-off
Interface : RS-232, Parallel, USB, PS/2 keyboard interface, Internal Ethernet print server, USB HOST
Power : 100-240V universal switching power supply
Other : Real-Time-Clock
Cutter : Heavy duty cutter
Firmware Fonts : Five alpha-numeric fonts, OCR-A, OCR-B
Font Direction : 0,90,180,270 degrees
Bar Code Syhmbologies : Code 39, Code 93, Code128UCC, Code 128 subsets A.B.C, Codabar
                                      Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E,
                                      EAN and UPC 2 digital add-on PDF-417, Maxicode, DataMatrix
Ribbon Width : 50.8 mm ~ 178 mm (2“ ~ 7“)

Ribbon Length : 450m
Environment : Operation:5∼40 , 30∼85%, Storage:-10∼60 , 20∼95%

TTP-3610MT

ZM420 Compatible

Resolution : 300dpi(12dots/mm)
Printing Speed : 50.8mm - 254mm per second(2.0-10.0ips)
Memory : 512 MB Flash, 256MB DRAM
              SD flash memory card slot for flash memory expansion
Width : 168 mm (6.61")
Length : 6,604 mm (260“)
