OPTICAL
CPU : 32 Bit RISC, DSP 600MHz
Image Sensor : 752 * 480 CMOS
Target Distance : 4 ~ 30 Cm from the camera face
Viewing Angle Horizontal : 45°, Vertical 45°
Symbologies : 2D:PDF417, QR Code, DataMatrix etc. Hot code
1D:Code128,EAN-13 ,EAN-8 ,Code39,UPC-A ,UPC-E, Codabar, China post 25，
Interleaved 2 of 5, ISBN/ISSN，Code 93 etc.
Interface : RS-232C, USB
MECHANICAL
Dimensions : 56mm X 60mm X 29.5mm
Weight : 100g
Cable Length : RS232C: 1.8M(6 ft), USB: 1.8M(6 ft)
Body Material : ABS Plastic
ELECTRICAL
Power Supply : +4.75 to 5.25V, Typical 180mA, Peak 400mA
Standby Current : 500mA 5 VDC
DURABILITY
Trigger Switch : 1 million Actuations
Cable : 100,000 Bending at 90 degree with 500g weight
Shock Resistance : 1.8 meter drop onto Concrete Surface
ENVIRONMENTAL
Temperature : Operating : 0 ~ 50°C, Storage : -20 ~ 65°C
Humidity : Operating : 10% ~ 80%, Storage : 0% ~ 95%
Certification : FCC Class B & CE
