TSK-200  (Aluminum)

MODEL : TSK-200T(TTL), TSK-200K(K/W), TSK-200R(RS-232), TSK- 200U(USB)

INTERFACE : TTL, K/W, RS232, USB

WEIGHT(W/O CABLE) : 530g, 550g, 550g, 550g

POWER CONSUMPTION : 12mA, 75mA, 75mA,75mA

POWER SUPPLY : K/W, USB : DC5V±10% DC5V±10%
                            RS-232 : DC6V∼9V 300mA

RESOLUTION : 4mil(0.10mm)

CASE : Aluminum

DIMENSIONS : 125X52X30mm

SCAN SPEED : 2~40ips

PCS : 0.6 ~ 0.9

DOF : 10~80mil

AMBIENT LIGHT REJECTION : 3000LUX

SYMBOLGIES : UPC/ENA/JAN, CODE39 INTERLEAVED 2OF 5,STANDARD2OF5,MATRIX5,
                      CODABAR,COED128,INDUSTRIAL2OF 5,CODE93,CODE3 OF5

OPTIONAL : INFRARED (940NM) OR VISIBLE RED(66ONM) 　
                  MODULE,PARTS SUPPLY AVAILABLE(SSR-1000 SERIES ONLY)

TSK-250  (PLASTIC)

MODEL : TSK-250T(TTL), TSK-250K(K/W), TSK-250R (RS-232)

INTERFACE : TTL, K/W, RS232

WEIGHT(W/O CABLE) : 52g, 66g, 66g

POWER CONSUMPTION : 5mA, 37mA, 37mA

POWER SUPPLY : DC 5V±10% DC5V±10% DC5V±10%

RESOLUTION : 4mil(0.10mm)

CASE : ABS PLASTIC

DIMENSIONS : 100X34X28mm

SCAN SPEED : 2~40ips

PCS : 0.6 ~ 0.9

DOF : 10~80mil

AMBIENT LIGHT REJECTION : 3000LUX

SYMBOLGIES : UPC/ENA/JAN, CODE39 INTERLEAVED 2OF 5,STANDARD2OF5,MATRIX5,
                      CODABAR,COED128,INDUSTRIAL2OF 5,CODE93,CODE3 OF5

OPTIONAL : INFRARED (940NM) OR VISIBLE RED(66ONM) 　
                  MODULE,PARTS SUPPLY AVAILABLE(SSR-1000 SERIES ONLY)
