Depth of Field : 0mm - 215mm (0” - 8.5”) for 0.33mm (13mil) bar codes

Width of Field : 60mm (2.4”) @ face ; 105mm (4.1”) @ 216mm (8.5”)

Scan Speed : 1200 scan lines per second

Scan Pattern : 5 fields of 4 parallel lines (omnidirectional)

Minimum Bar Width : 0.13mm (5.2mil)

Dimensions : 150mm (5.9") H x 105mm (4.1") D
                    x Orb Width : 80mm (3.1”) Base Width : 102mm (4.0”)

System Interfaces : PC Keyboard Wedge, RS232, OCIA, Light Pen Emulation, IBM 468x/469x,
                              Stand Alone Keyboard, USB (low speed and full speed)

Light Source : Visible Laser Diode 650nm ± 10nm

Weight : 410g (14.5oz)

Shock : Designed to withstand 1.2m (4.0') drops
