CPU : 32Bit
Scan rate : 300 Scans per Second
Resolution : 4mil (0.1mm)
Photo Sensor : 2500 Pixel Linear CCD
Illumination : 660nm Visible Red LEDS
Skew Angle : ±65 Degree
Pitch Angle : ±50 Degree
Field Width : 170mm (15mil)
Depth of field : 30~400mm
Symbologies : UPC/EAN/JAN, Code39, Interleaved 2 of 5 Standard 2 of 5, Matrix 2 of 5,
Industrial 2 of 5, Codabar, Code128, MSI, Plessey, Code93, GS1
Interface : USB ( HID ), 메모리 방식 동글적용
Data storage Memory : 184 Kbyte (ex. UPC/EAN 8,000 events)
Radio Range : 50M open air
MECHANICAL
Dimensions : 95mm x 70mm x 160mm
Weight : 184g
Body Material : ABS Plastic
ELECTRICAL
Power Supply : (3.7 Voltage) Li-Pol 1500mA
Power Consumption : Normal 3mA Max 140mA(CCD)
Battery Life : Up to 50,000 Scans
DURABILITY
Trigger Switch : 1 million Actuations
Shock Resistance : 1 meter drop onto Concrete Surface
ENVIRONMENTAL
Temperature : Operating : 0 ~ 50°C, Storage : -10 ~ 60°C
Humidity : Operating : 10% ~ 80%, Storage : 10% ~ 95%
Mechanical Shock : Functional after 1.5m (5ft) drops
ESD Protection : Functional after 15kV discharge
