| DESCRIPTION |
STANDARD |
ORDER MAD |
| SUBSTRATE |
OPP, CPP, PET AND THE OTHER PLASTIC FILMS |
| COLOR UNIT |
1 ~ 10 COLORS |
| PRINTING WIDTH |
MAX.1200mm |
500 ~ 1300mm |
| MACHINE SPEED |
MAX. 220m/min |
| PRINTING CYLINDER |
CENTER HEIGHT |
FL. +730mm |
| CHUCKING TYPE |
PNEUMATIC SHAFTLESS TYPE |
| DIA. & SURFACE |
Dф(130 ~ 300mm), L (900 ~ 1250mm) |
L (550 ~ 1350mm) |
| IMPRESSION SYSTEM |
ONE ROLL SWING ARM TYPE |
THREE ROLL TURRET TYPE |
| TURRET WINDER |
DIAMETER |
MAX.ф600mm |
MAX.ф800mm |
| CORE CHUCKING TYPE |
PNEUMATIC SHAFTLESS CHUCKING |
AIR EXPANSION SHAFT |
| REEL CHANGE |
AUTOMATIC SPLICING SYSTEM |
| DRYER |
NOZZLE TYPE |
JET NOZZLE AND QUICK RETURN TYPE |
| HOOD OPEN TYPE |
PNEUMATIC CYLINDER |
| HEATING SOURCE |
STEAM CONVECTOR, GAS BURNER, ELECTRIC HEATER |
| TENSION CONTROL SYSTEM |
AUTOMATIC WEB TENSION CONTROL WITH D.C MOTOR OR A.C VECTOR MOTOR |
