| DESCRIPTION |
STANDARD |
ORDER MADE |
| SUBSTRATE |
OPP, CPP, PET AND THE OTHER PLASTIC FILMS, PAPER, AL - FOIL |
| WORKING WIDTH |
MAX. 1100mm |
| MACHINE SPEED |
MAX.180m/min |
| ANCHOR COATING |
DIRECT GRAVURE ROLL COATING TYPE |
| COOLING ROLLER |
ф500mm |
| TENSION CONTROL |
FULL AUTOMATIC CONTROL SYSTEM |
| COATING THICKNESS |
15 ~ 45?/td> |
| RESIN |
LDPE, PP, LLDPE(LAMINATING GRADE) |
EVA, EAA, IONOMER |
| EXTRUDER |
OUTPU |
150kg/Hr |
250kg/Hr |
| SCREW TYPE |
90mm, L / D = 30 / 1 |
100mm, L / D = 30 / 1 |
| LIP LENGTH |
1300mm |
| WINDING SYSTEM |
TURRET ARM TYPE, CENTER WINDING SYSTEM |
| CORE CHUCKING |
AIR EXPANSION SHAFT PNEUMATIC SHAFTLESS TYPE |
| WINDING DIAMETER |
UNWINDER |
ф600mm |
| SANDWICH |
ф500mm |
ф600mm |
| REWINDERR |
ф800mm |
| DRIVING SYSTEM |
DC MOTOR |
A.C VECTOR MOTOR |
