| DESCRIPTION |
STANDARD |
ORDER MAD |
| SUBSTRATE |
OPP,CPP,PET AND THE OTHER PLASTIC FLIMS |
| COLOR UNIT |
1) 1 - 10 color straight printing
2) 9 coloe printing with back-side cold seal at the 10th
station using turn-bar
3) 8 color printing with laminatioon at 9th station and
cold seal at 10th station on same side |
| MACHINE SPEED |
MAX 350m/min |
| PRINTING CYLINDER |
CENTER HEIGHT |
FL. + 800mm |
| CHUCKING TYPE |
PNEUMATIC SHAFTLESS TYPE |
| DIA. & SURFACE |
Dф(130 ~ 300mm), L (900 ~ 1250mm) |
L (550 ~ 1350mm) |
| IMPRESSION SYSTEM |
ONE ROLL SWING ARM TYPE |
THREE ROLL TURRET TYPE |
| TURRET WINDER |
DIAMETER |
MAX.ф600mm |
MAX.ф800mm |
| CORE CHUCKING TYPE |
PNEUMATIC SHAFTLESS CHUCKING |
AIR EXPANSION SHAFT |
| REEL CHANGE |
AUTOMATIC SPLICING SYSTEM |
| DRY OVEN |
NOZZLE TYPE |
JET NOZZLE AND QUICK RETURN TYPE |
| HOOD OPEN TYPE |
PNEUMATIC CYLINDER |
| HEATING SOURCE |
STEAM CONVECTOR, GAS BURNER, ELECTRIC HEATER |
| TENSION CONTROL SYSTEM |
AUTOMATIC WEB TENSION CONTROL WITH SECTIONAL DRIVE A.C VECTOR MOTOR SYSTEM |
