Features
USB Host
ㆍ2 USB interface channels
ㆍVarious access devices can be used using the USB I/F.
ㆍAccess to mouse, keyboard, a USB external hard disk, barcode reader, and USB hub is possible. Continuous upgrades and developments to cope with other drivers are in the works.
A type USB Cable (XPO-USBC)
ㆍUSB cable is used for screen data transmission and XP-Runtime updates.
ㆍThe versions before XP-Builder 1.30 are not installed with the USB driver, thus must be installed.
Effective Use of USB Memory
ㆍPLC data can be saved in a CF card or USB memory. If necessary, they are converted into a CSV format to be used to prepare daily and monthly reports.
ㆍWhen drawing files using the XP-Builder are saved in a CF card or a USB memory and copied to the XGT Panel, they can be executed without being sent via cables.
ㆍWhen there are several XGT Panels, one CF card or USB memory can be used to copy each XGT panel, allowing a setup.
ㆍA CF card or a USB memory can be used for engine updates and upload/download of drawing files.
Specifications
General Information
| Item | Description | Standard | |||
|---|---|---|---|---|---|
| Ambient Temperature | 0℃∼+50℃ | ||||
| Storage Temperature | -20℃∼+60℃ | ||||
| Ambient Humidity | 10∼85%RH, without dew condensation | ||||
| Storage Humidity | 10∼85%RH, without dew condensation | ||||
| Vibration Resistance | -20℃∼+60℃ | Counts | |||
| Frequency | Acceleration | Amplitude | 10 times each direction (X, Y and Z) |
IEC 61131-2 | |
| 5≤ f < 9㎐ | - | 3.5mm | |||
| 9 ≤ f ≤ 150㎐ | 9.8m/s2 | - | |||
| Continuous Vibration | |||||
| Frequency | Acceleration | Amplitude | |||
| 5≤ f < 9㎐ | - | 1.75mm | |||
| 9 ≤ f ≤ 150㎐ | 4.9m/s2 | - | |||
| Shock Resistance | Maximum shock acceleration: 147m/s 2 (15g) Authorization time: 11㎳ Pulse waveform: Half-sine wave pulse (3 times each of X,Y and Z) |
IEC 61131-2 | |||
| Noise Resistance | Square wave impulse noise | AC: ±1,500V DC: ±1,000V | LS ELECTRIC Standards | ||
| Electrostatic discharge | Voltage: 6 kV (Contact discharge) | IEC 61131-2, IEC 61000-4-2 | |||
| Radiated electromagnetic field noise | 27 ~ 500MHz, 10V/m | IEC 61131-2, IEC 61000-4-3 | |||
| Fast transient/Burst noise | Power module: 2 kV, Communication interface: 1kV | IEC 61131-2, IEC 61000-4-4 | |||
| Operating Ambience | Free from corrosive gas and excessive dust | ||||
| Altitude | 2,000m (6,562ft) or below | ||||
| Pollution Degree | 2 or under | ||||
| Cooling Method | Natural air-cooling | ||||
