Properties

Condition

Data

Operating temp. (℃)

KS M 3006 (UL224)

-45℃ ~ +105℃

Tensile strength

KS M 3006 (UL224)

over 1.5kgf/mm²

Ultimate elongation

ISO/R 1183 Method A

over 350%

Specific gravity

ISO 868

1.1~1.22g/cm²

Hardness

45-60D

After Aging

Tensile Strength

KS M 3515 (UL224)

over 1.2kg/mm²

Elongation

KS M 3515 (UL224)

over 300%

Thermal endurance

IEC 216 (UL224)

more 120℃

Low-temp. flexible

ASTM D 2617 (UL224)

no Crack

Dielectric strength

ASTM D 149 (UL224)

more 200kV/cm

Volume resistivity

KS M 3034 (UL224)

1 X 10Ω·cm

Dielectric constant

ASMT D 150 (UL224)

5

Water absorption

KS M 3027

under 0.2%

In oil bath

Tensile strength

KS M 3006 (UL224)

more 1.4kgf/mm²

Elongation

KS M 3006 (UL224)

more 300%

Corrosion

UL224

no damage

Hot-melt adhesive

Softening point

KS M 3076

81℃

Water absorption

KS M 3027

under 0.5%

Peeling test

ASTM D 1000

50kg/mm

Materials

Flame Retardant Adhesive

Non Flame Retardant Adhesive

Flame

Non Flame

Description

Unit Length (M)

Expanded inner Dia (mm)

Recovered Inner Dia (mm)

Recovered Thickness(mm)

9/3

1.2

9+2

3

2.0±0.2

12/4

1.2

12+2

4

2.0±0.2

16/5

1.2

16+2

5

2.0±0.2

22/7

1.2

22+3

7

2.5±0.2

28/9

1.2

28+3

9

2.6±0.2

33/11

1.2

33+3

11

2.7±0.2

38/13

1.2

38+3

13

2.7±0.2

45/14

1.2

42+5

14

2.7±0.2

55/18

1.2

55+5

18

2.9±0.3

65/22

1.2

65+5

22

3.0±0.3

75/25

1.2

75+5

25

3.2±0.3

85/28

1.2

85+5

28

3.2±0.3

100/33

1.2

100+7

33

3.2±0.4

120/38

1.2

115+7

38

3.2±0.4

140/47

1.2

140+7

47

3.2±0.4
