제품 상세 정보
Small and easy portable
Features
| Profile | Profile infusion condition (flow rate, delivery volume, delivery time) differently every hour, up to 24 hours. |
|---|---|
| Drug labeling (EASY MODE) | Save 3 of drug's names and infusion data |
| Self testing | Every time the unit turns on, self testing is proceeded. |
| K.V.O.(Keep Vein Open) | When the delivery volume has been reached, flow rate turns into K.V.O. rate ( adjustable from 0.1ml/h ~0.9ml/h) automatically. |
| Keypad lock function | Keypad is locked with or without password depend on its using condition. |
| Infusion setup | Flow rate / Delivery volume / Total infused volume |
| Buzzer | 3 step |
| Occlusion level | 3 step (4psi~20psi) |
| Bolus | ON/OFF, Adjustable (1~30ml/h) |
| History call back | Display up to last 15 infusion data |
| Data saving years | 5 years |
| Strengthen safety | Double CPU stop on error |
| Avoiding FREE FLOW | |
| Dosage mode(Body weight mode) | Automatically calculate |
| Recharge battery | |
| Battery recharging time | 4 hours/td> |
| Battery operating time | 4 hours (25ml/h ) |
Specification
| FLOW RATE | 0.1 ~ 250ml/h |
|---|---|
| BOLUS RATE | 0.1~60.0ml/h |
| DELIVERY VLUME | 0.1ml ~ 999.9ml (in 0.1ml increments) |
| PURGE RATE | 1mL/h ~ 30.0mL/h |
| KVO RATE | 0.1mL/h ~ 0.9mL/h |
| LOCK TIME | 1~ 999min (±1min) |
| ACCURACY | ±3% |
| OPERATING METHOD | Peristalsis |
| LEVEL OF OCCULATION | 4psi ~ 20psi ( 3 STEPS ) |
| PROFILE FUCTION | Save event, Language selection (optional) Connect to USB , History call back |
| POWOR | A/C : 100-240 V~ / 50-60Hz, DC 7.4V Class 1, Internal power supply, TypeCF |
| OPERATION CONDITION | +5 ~ 45°C, 90% RH (no condensation) |
| STORAGE CONDITION | -20 ~ 60°C, 95% RH (no condensation) |
| ALARM | AIR IN LINE, OCCLUSION, DOOR OPEN, EMPTY CONTAINER, K.V.O. RATE (INFUSION COMPLETION),LOW BATTERY, REPEAT ALARM, FLOW ERROR (I.V. SET FREE FLOW PROTECTION), DEIVCE MALFUNCTION |
