Manufacturer
WOOJIN SERVO
Product Type
Machine
Brand
-
SKU
136900
Product Name
Rotary Optical, Linear Optical
Model Name
BOS10, BOS15
Size
-
Weight
-
Product Details
Product Kinds
Rated Voltage : 5VDC
DC Resistance : 13Ω
Operating Angle : 50degrees
Life Time : 5 million cycles
■ SPECIFICATION
| Rated Voltage | 5 VDC |
|---|---|
| DC resistance | 13Ω |
| Time constant of temperature rise |
0.5 minutes |
| Heat resistance class | Class E (120˚C) |
| Operating angle | 50 degrees |
| Pulse duration | 100 to 200 ms |
| Response speed | 5 VDC : 13ms or less |
| 12 VDC : 8ms or less | |
| Life time | 5 million cycles |
| Mass | 11g |
