Manufacturer
Woojin Servo System
Product Type
Machine
Brand
-
SKU
136733
Product Name
Stepping Motor Driver
Model Name
HTD542
Size
-
Weight
-
Product Details
- Basic Frequency 80MHz
- Maximum Input Pulse Frequency more than 2MHz
- Maximum Output current 4.2A
- Maximum Input Voltage 50VDC
- Maximum Number of Subdivisions 25,000
- Maximum Motor No-load Running Speed 4000RPM
