This product is manufactured by
DAE-BOONG ELECTRIC
Receive Indicator
Model Name
D-60
Data
Drawing-Dae Boong Electric-Meters-Frequency Meter
Manufacturer information
DAE-BOONG ELECTRIC
Electric measuring machine manufacturer, Wattmeter, Power factor indicator, Converter, Transformer, Transducer and more
Inquiry
How to order
Problem with product info?
Update request
Manufacturer
DAE-BOONG ELECTRIC
Product Type
Machine
Brand
-
SKU
135159
Product Name
Receive Indicator
Model Name
D-60, D-68, D-80, D-100, D-200, D-300, D-70, D-800, D-110, D-96
Size
-
Weight
-
Product Details
Overview
This option meter of operating principle are the rectifier type and the moving coil type.
Model
Meter rating
| Type | Voltage | Current |
rectifier type |
AC 18~600V | - |
coil type |
DC 1~600V | 0~10mA |
| 4~20mA |
Specification
| Shape of case | Type | Freq. | ||
| Rectangular (60x60mm) | D-60 |  |
50~60Hz | 0.5 |
| D.C | 1K Ω/v | |||
| Rectangular (80x80mm) | D-80 |  |
50~60Hz | 0.5 |
| D.C | 1K Ω/v | |||
| Rectangular (100x83mm) | D-100 |  |
50~60Hz | 0.5 |
| D.C | 1K Ω/v | |||
| Rectangular (80x80mm) | D-800 |  |
50~60Hz | 0.5 |
| D.C | 1K Ω/v | |||
| Rectangular (110x110mm) | D-110 |  |
50~60Hz | 0.5 |
| D.C | 1K Ω/v | |||
| Rectangular (72x72mm) | D-200 |  |
50~60Hz | 0.5 |
| D.C | 1K Ω/v | |||
| Rectangular (98x98mm) | D-300 |  |
50~60Hz | 0.5 |
| D.C | 1K Ω/v | |||
| Rectangular (70ø) | D-70 |  |
50~60Hz | 0.5 |
| D.C | 1K Ω/v |
