제품 상세 정보
For high speed production of regular wire welded coil nail This state of the are compact collator will produce any type of welded wire coil nails up to 3,000 nails in a coil and length nails, Equipped with automatic coiler & cutter, automatic rubber bander , coating, drying, auto ejection & rotating abstract table Mirror type collator - Less man-power required.
SPECITIFICATION
| Collating Speed | Up to 3,000 Nails per Min. | |
|---|---|---|
| Nail Size | Length | 3/4" to 4"(19~100mm) |
| Diameter | .0625" to .148 "(1.60~3.77mm) | |
| Nail Spec | Angle | 0° to 16° Degree |
| Nails per Coil | 225 to 400 Nails(Up to 3,000 Nails) | |
| Electric Power | 30KVA, 3 phase/220V/50~60Hz | |
| Electronic Mfg | As Specified by Customer | |
| Pneumatic Mfg | As Specified by Customer | |
| Space Required | 16L x 4.3W x 6H Feet (4,800L x 1,300W x 1,800H mm) | |
| Weight | 7,700 Lbs (3,500kg) | |
SAMPLE PRODUCT
