항목

단위

YGS-6022SCYZ

YGS-4320SCYZ

YGS-3018SCYZ

YGS-3015SCYZ

YGS-2512SCYZ

Capcity

테이블면적
(길이×폭)

mm

6050×2200

4150×2000

3050×1800

3050×1500

2550×1200

표준척의크기
(길이×폭)

mm

6000×2200

4000×2000

3000×1800

3000×1500

2500×1200

테이블 상면에서
숫돌중심까지의 거리

mm

0~830

0~830

0~830

0~830

0~830

최대 통과 폭

mm

2750

2750

2250

1750

1450

Table

좌우 이동 속도(평균)

m/min

4~30

4~30

4~30

4~30

4~30

전후
수동이송

다이알 1눈금당
이송량

mm

0.1,1.0,10

0.1,1.0,10

0.1,1.0,10

0.1,1.0,10

0.1,1.0,10

다이알 1눈금당
이송량

mm

0.001,0.01,0.1

0.001,0.01,0.1

0.001,0.01,0.1

0.001,0.01,0.1

0.001,0.01,0.1

전후
자동이송

간헐이송

mm

1~99

1~99

1~99

1~99

1~99

연속이송

m/min

0~3

0~3

0~3

0~3

0~3

Grinding head

자동 절입 이송량

mm

0.001~0.03

0.001~0.03

0.001~0.03

0.001~0.03

0.001~0.03

수동 절입
이송량

핸들1회전당
이송량

mm

0.1,1.0,2.5

0.1,1.0,2.5

0.1,1.0,2.5

0.1,1.0,2.5

0.1,1.0,2.5

다이알 1눈금당
이송량

mm

0.001,0.01,0.025

0.001,0.01,0.025

0.001,0.01,0.025

0.001,0.01,0.025

0.001,0.01,0.025

Grinding Wheel

외경×폭×내경(60Hz)

mm

Ø510×100×Ø203.2

Ø510×100×Ø203.2

Ø510×100×Ø203.2

Ø510×100×Ø203.2

Ø510×100×Ø203.2

회전수(50Hz/60Hz)

r.p.m

980/1200

980/1200

980/1200

980/1200

980/1200

Motors

스핀들용

Kw/p

15/6

15/6

15/6

15/6

15/6

유압펌프용

kg

22/6

22/6

22/6

15/6

11/6

기계중량(약)

kg

65,000

45.000

33.500

32,000

22.000

구분

A

B

C

YGS-6022SCYZ

16500

4620

3650

YGS-4320SCYZ

12580

4620

3650

YGS-3018SCYZ

10935

3915

3650

YGS-3015SCYZ

10935

3915

3650

YGS-2512SCYZ

8500

2965

3000

구분

a

b

c

d

e

f

g

YGS-6022SCYZ

100

1250

1250

2200

510

830

120

YGS-4320SCYZ

100

1250

1250

2000

510

830

120

YGS-3018SCYZ

100

1125

1125

1800

510

830

120

YGS-3015SCYZ

100

900

900

1500

510

830

120

YGS-2512SCYZ

100

700

700

1200

510

830

120
