Features
- Collects smoke, fine dust and oil mist
- Semi-permanent filter reduces industrial waste
- Occupational disease prevention and productivity improvement
- Resolution of complaints
- Easy to install and move (minimize vibration noise)
- Easy to install in narrow space
* Application of oil cutting oil for industrial and machine tools (non-water soluble)
* As it is compact and light, it can be installed on top of machine tools
Dust treatment process
Specification
|
MODEL |
A |
B |
C |
D |
E |
F |
G |
ØH |
|
YEC-10 |
230 |
430 |
530 |
750 |
550 |
180 |
475 |
150 |
|
YEC-20 |
270 |
540 |
550 |
770 |
650 |
220 |
500 |
150 |
|
YEC-30 |
330 |
540 |
550 |
770 |
650 |
270 |
500 |
150 |
|
YEC-40 |
500 |
540 |
960 |
1160 |
670 |
440 |
920 |
200 |
|
MODEL |
YEC-10 |
YEC-20 |
YEC-30 |
YEC-40 |
|
POWER |
Single phase 220V 50/60Hz |
|||
|
Power consumption(Kw) |
155 |
250 |
320 |
450 |
|
Current (A) |
0.8 |
1.1 |
1.4 |
1.9 |
|
FAN |
Backward fans |
|||
|
RPM |
2550 |
2950 |
2700 |
1750 |
|
Air flow (㎥/min) |
7 |
10 |
15 |
25 |
|
Static pressure (mmAq) |
40 |
70 |
80 |
34 |
|
Noise (dB±2) |
62 |
62 |
75 |
74 |
|
Efficiency (%) |
95 |
95 |
95 |
95 |
|
Weight (kg) |
25 |
32 |
40 |
80 |
