펌핑속도

1500L/min

도달진공

≤1X10-3 Torr

최대출력

3.7kW(5hp)

Pumping Speed

1500ℓ/min

Ultimate Pressure

Gas Ballast Open

5X10 -2 Torr ( 6.7 Pa)

Gas Ballast Closed

≤1X10 -3 Torr ( 1.3X10 -1 Pa )

Power Input

Standard

Φ3 220VAC/380VAC 50/60 Hz

Customer’s Request (Voltage, Frequency and phase)

Full load Power

3.7kw (5 HP)

Motor Speed

1,700 rpm

Inlet

Standard

NW40

Option I

+ Hose Nipple : Φ36 OD for NW40

Option II

+ PT Nipple : 1&1/4 for NW40

Option III

User Requested Type

Weight Φ3

101.5kg

Oil Capacity

6200cc (6.2 L)

Overall Dimension (mm)

264(W) X 777.5(L) X 442(H)
