• 1/4” 613K pixels SONY Super HAD II dual scan CCD
• 700TV lines of highest resolution - HR7 mode
• Progressive scan 612,688 pixel
• Optical 36x power zoom and 32x digital zoom
• Dual scan 512x WDR
• Intelligent detection for baggage removal and loading(Option)
• IP66 Outdoor Application
• 255 Presets - Pan : 380°/sec ±0.1°, Tilt : 150°/sec ±0.01° Accuracy
- 64 steps proportional to zoom
• 8 programmable Tours
• 4 Patterns
• Digital Auto Flip
• Polycarbonate Dome Cover (166Ø)
• 8 Alarm Inputs(Normal Open or Normal Close), 2 relay outputs
• 8 Auto Scan(Programmable speed and diagonal scan)
• Pan Motion Allows 0.1-90°/sec Pan Speed
• Programmable Privacy Masking(8 Zones)
• RS-422, RS-485 communication support and remote program update
• Multiple protocol
• Built-in Menu System for Setup of Programmable Functions
• Programmable Zoom Speeds
• AC 24V, 1A / AC 24V, 2A(Outdoor Housing)
• Digital Noise Reduction (2D + 3D)
• Digital Image Stabilizer (DIS)
• High Light Compensation (HLC) Function
