Resolution : 203dpi(8dots/mm) TX200
300dpi(12dots/mm) TX300
Printing Speed : 50.8mm-203mm per second(2.0-8.0ips) TX200
50.8mm-156mm per second(2.0-7.0ips) TX300
Memory : 12MB Flash, 128 MB DRAM
Width : 108 mm (4.25") TX200
106 mm (4.17") TX300
Length : 25,400mm TX200
11,430mm TX300
Material : Double-walled Plastic
Operation Panel : LED(Power, Error, On line), Switch
Dimension : 226 mm (W) x 198 mm (H) x 332 mm (D)
Weight : 3.75kg
Sensors : Label gap, Ribbon end, Black-mark, Head open, Case open, Peel-off
Interface : RS-232, Internal Ethernet, 10/100 Mbps, USB 2.0, USB HOST
Power : 100-240V universal switching power supply
Other : Real-Time-Clock ( option )
Cutter : Guillotine cutter
Firmware Fonts : Five alpha-numeric fonts, OCR-A, OCR-B
Font Direction : 0,90,180,270 degrees
Bar Code Syhmbologies : Code 39, Code 93, Code128UCC, Code 128 subsets A.B.C, Codabar
Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E,
EAN and UPC 2 digital add-on PDF-417, Maxicode, DataMatrix
Label Width : 19mm-112mm
Label Thickness : 0.055mm0.254mm
Roll Size : 127mm OD(5.0" OD)
Roll Core Diameter : 25mm-38.1mm
Black-Mark Hight : 1.5mm-3mm(0.06"-0.12")
Ribbon Width : 40mm-110mm(1"-4")
Ribbon Length : 300m
Environment : Operation:5∼40 , 30∼85%, Storage:-10∼60 , 20∼95%
